Dustproof Accurate Data Ra150s Bench Top Surface Photometry Profilometer

Customization:	Available
Product Name:	Surface Roughness Profilometer
Keywords:	Roughness Contour Meter

Basic Info

Model NO.	RA150S
Material	Metal
Feature	High Range, High Accuracy, High Resolution
Application	Test Roughness Value and Profile
Transport Package	Wooden Box
Specification	International Standards
Production Capacity	500 Sets

Product Description

PRECISION SURFACE ROUGHNESS PROFILOMETER – ALL-IN-ONE MEASUREMENT SOLUTION

Discover the ultimate surface roughness and contour measurement machine engineered for precision manufacturing.

This advanced roughness profiler integrated system combines high-precision grating measurement technology, ultra-smooth grinding guide rails, and a non-contact linear motor to deliver unparalleled accuracy.

Equipped with a high-performance computer control system and multi-functional analysis software, it measures surface roughness parameters, profile contours, and waviness with exceptional reliability. Ideal for industries demanding micron-level precision.

Specifications

Project / Model		IPRE-RA150S
X-axis Guide Rail	Moving accuracy	≤±(1+\|0.02L\|)μm
X-axis Grating Ruler	Resolution	0.01μm
Date Sensor	Resolution	0.001μm (Roughness test)
Linear precision		≤±(0.8+\|0.05H\|)μm
Circular arc		≤±(1.2+R/12)μm
Straightness		≤0.5μm/100mm
Roughness Measurement
Test range	Z1 axis	±20mm (Full range)
Evaluation parameters		Ra, Rz, Rq, Rt, Rp, Rv, Rc, Rdc, Rsk, Rku, Rsm, Rmr, Rdq, Rmr(c); Wa, Wz, Wq, Wt...
Sampling length L		0.08, 0.25, 0.8, 2.5, 8 (mm)
Contour Measurement
Measure range	X-axis / Z-axis	≤180mm / ≤500mm (Adjustable)
Instrument size		1200×750×1800 (mm)
Weight		About 350Kg

Key Features

⭐ HIGH-PRECISION GRATING SYSTEM

Equipped with advanced grating sensor technology ensures exceptional measurement accuracy and repeatability for demanding analysis.

⭐ NON-CONTACT LINEAR MOTOR

Smooth, vibration-free scanning ensures consistent and distortion-free measurement results across all surfaces.

Intelligent Software System

📊

Powerful data processing and report printing in various formats; measurement records can be archived or queried easily.

📏

Wide measurement range meeting requirements for wire rod, bearings, threads, and contour special measurements.

⚙️

Supports multiple standards including ISO, DIN, JIS, and ANSI for comprehensive parameter settings.

💾

Large-capacity database storage for recording and saving all historical verification results.

Application Scenarios

Frequently Asked Questions

Q1: Are you a manufacturer or a trading company? A1: Established in 2013, we operate our own manufacturing facility while also managing professional international trade services.

Q2: What international quality certifications do your products hold? A2: Our products and processes comply with ISO9001, ISO14001, ISO45001, and EU CE certifications, ensuring high global standards.

Q3: What is the typical lead time for equipment delivery? A3: We maintain stock for most standard products. Delivery usually occurs within 7 days. For customized solutions, the lead time is approximately 1-2 weeks.

Q4: What payment methods are accepted for international orders? A4: We accept a variety of payment methods including T/T, L/C, D/P, PayPal, Western Union, and MoneyGram.

Q5: What is the Minimum Order Quantity (MOQ)? A5: For our high-precision measurement equipment, the minimum order quantity is 1 set.

Q6: Can the analysis software be customized? A6: Yes, our intelligent software functions can be customized and tailored according to specific customer requirements and industry standards.
